Vortex Crossfire® HD 1400 HCD Corrected Shoot-To Range Reticle Rangefinder

If you’re on the hunt for the perfect go-to laser rangefinder for bow and rifle hunters alike, you’ve found it in the Crossfire™ HD 1400. The Crossfire® HD 1400 has everything you need and nothing you don’t. With a 1,400-yard max range (750 on deer), you get plenty of power to range and, thanks to the HD optical system, you’ll have the power to pick apart any landscape. To match any hunting environment, the Crossfire® HD 1400 has three target modes (Normal, First, Last) and two ranging modes (HCD and LOS). A red TOLED display keeps the readout clear in any lighting conditions and, at just 4.8 ounces, the Crossfire™ HD 1400 hunts hard and carries light.

INCLUDED IN THE BOX

• Soft Carry Case
• Wrist Lanyard
• Bungee Cord Lanyard
• Lens Cloth
• Hook and Loop Harness Attachment
• CR2 Battery

Magnification	5x
Objective Lens Diameter	21 mm
Reticle	HCD Corrected Shoot-To Range
Range Reflective (yards)	1400 yds
Range Tree (yards)	950 yds
Range Deer (yards)	750 yds
Max Angle Reading	+ / - 89 degrees
Linear Field of View	367 feet/1000 yards
Angular Field of View	7 degrees
Eye Relief	16 mm
Length	4.0 inches
Width	1.3 inches
Weight	4.8 oz



FEATURES:

HD Optical System Optimized with select glass elements to deliver exceptional resolution, cut chromatic aberration, and provide outstanding color fidelity, edge-to-edge sharpness and light transmission. Red TOLED Display Optimized for low light. .1 Yard Increment Display Displays .1 yd increments out to 999.9 yards. XR Lens Coatings Premium anti-reflective coatings on all air-to-glass surfaces provide superior light transmission for exceptional clarity and low-light performance. Diopter Adjusts for difference in a user's eye. ArmorTek® Ultra-hard, scratch resistant coating protects exterior lenses from scratches, oil, and dirt. Waterproof O-ring seals prevent moisture, dust, and debris from penetrating for reliable performance in all environments. Ranging Format Range in yards or meters.



HCD CORRECTED SHOOT-TO RANGE

The Crossfire HD 1400 uses HCD (Horizontal Component Distance) angle-compensated ranging technology to give bow and rifle shooters the critical distance data needed to make accurate shots.

Parts Diagram (PDF)

Product Manual (PDF)
